G125-FC12005L0-0300F

Gecko Cable Assembly (compatible with latches), Female-to-Female, white 26 AWG cable, 300mm long, 10+10 contacts

Download Datasheet Request Sample
In-Stock: 13
Factory Lead Time (wks): 18
All prices are in USD
SPQ: 10		 Quantity Unit Price Ext Price Packaging
10 $98.018 $980.18 Bulk/Loose
30 $89.043 $2671.29 Bulk/Loose

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeGecko
Pitch1.25mm (0.049")
GenderFemale
OrientationStraight
Connection TypeCable Assembly
Wire Size26 AWG
Number Of Rows2
Number Of Contacts20
Current Rating2.8A max individual contact, 2A max simultaneous (25°C)
Environmental Ratings-65°C to +150°C
Latching StyleCompatible with latches
Termination FinishGold
Housing MaterialPolyamide (Nylon) 4T
Flammability RatingUL94V-0
Weight12.779g
Dimensions300.00 x 15.05 x 4.90
End StackableNo
Mating Pin SizeØ0.4mm
Pcb MountingCable Assembly

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Insertion Removal Tool

Articles from this product series can be use in the following assortments:

Image 1 Image 1

Z125-902

 View Details

Use with Spare Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

G125-0010005

 View Details
Image 1 Image 1

G125-FW10300F94

 View Details

Use with Dummy Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

G125-0200005

 View Details

Use with Mating Products

Articles from this product series can be use in the following assortments:

Image 1 Image 1

G125-MS12005L0P

 View Details
Image 1 Image 1

G125-MS12005L1P

 View Details
Image 1 Image 1

G125-MS12005L2P

 View Details
Image 1 Image 1

G125-MS12005L3P

 View Details
Image 1 Image 1

G125-MV12005L0P

 View Details
Image 1 Image 1

G125-MV12005L1P

 View Details
Image 1 Image 1

G125-MV22005L0P

 View Details
Image 1 Image 1

G125-MV22005L2P

 View Details
Image 1 Image 1

G125-MH12005L1P

 View Details
Image 1 Image 1

G125-MH12005L3P

 View Details

Use with Primary Alternative

Articles from this product series can be use in the following assortments:

Image 1 Image 1

G125-FC12005L0-0150F

 View Details
