M50-3201245

1.27mm (0.05") Pitch DIL Horizontal Throughboard Socket Assembly, gold, 12+12 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 16
All prices are in USD
SPQ: 37		 Quantity Unit Price Ext Price Packaging
518 $2.28 $1181.04 Tube
1036 $2.18 $2258.48 Tube

Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyBBi
Product StatusActive
RangeARCHER
Pitch1.27mm (0.05")
GenderFemale
OrientationHorizontal
Connection TypePC Tail / Throughboard
Number Of Rows2
Number Of Contacts24
Current Rating1A per contact
Environmental Ratings-40°C to +105°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Termination FinishGold
Housing MaterialPolyamide (Nylon) 9T
Flammability RatingUL94V-0
Weight0.557g
Dimensions15.64 x 5.23 x 5.85
Above Board Height3.45mm
End StackableNo
Mating Pin Size0.4mm square
Pcb MountingPC Tail / Throughboard
