M7566-46

2.54mm (0.1") Pitch Open Top Jumper Socket, multi-usage, tin, Red

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 1000		 Quantity Unit Price Ext Price Packaging
3000 $0.148 $444 Bulk/Loose

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyBBi
Product StatusActive
RangeINDESS
Pitch2.54mm (0.1")
GenderFemale
OrientationVertical
Connection TypeJumper Socket
Number Of Rows1
Number Of Contacts2
Current Rating3A at 25°C
Environmental Ratings-40°C to +85°C
Housing MaterialPBT
Flammability RatingUL94V-0
Weight0.118g
Dimensions5.00 x 2.30 x 6.30
End StackableYes
Mating Pin Size0.64mm square
Pcb MountingJumper Socket
