M80-263FC04-00-00

Datamate Mix-Tek Female Cable Housing, 101Lok bayonet fixings, cavities for 4 x Power or Coax contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 21
All prices are in USD
SPQ: 10
Quantity Unit Price Ext Price Packaging
40 $12.65 $506 Bulk/Loose


Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch4.00mm (0.157")
GenderFemale
OrientationStraight
Connection TypeCable (Solder + Crimp)
Number Of Rows1
Current RatingDependent on assembled contacts
Environmental Ratings-55°C to +125°C
Jackscrew Style101Lok Bayonet Fixing with Slotted Head
Housing MaterialPPS
Flammability RatingUL94V-0
Weight1.13g
Dimensions26.00 x 5.50 x 10.80
End StackableNo
Pcb MountingCable (Solder + Crimp)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required

Use with Insertion Removal Tool

Articles from this product series can be use in the following assortments:

Use with Primary Alternative

Articles from this product series can be use in the following assortments:
