M80-4000000F1-04-PF1-00-000

Datamate Mix-Tek Female Vertical Throughboard Connector, Hexagonal slotted jackscrews, no signal contacts, 4 x 3.5mm Throughboard High Power contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 10		 Quantity Unit Price Ext Price Packaging
50 $33.113 $1655.65 Tube

Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch4.00mm (0.157")
GenderFemale
OrientationVertical
Connection TypePC Tail / Throughboard
Current Rating40A max per contact
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Jackscrew StyleFloating Jackscrew with Hex Slotted Head (Standard Gender)
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight2.067g
Dimensions26.00 x 5.50 x 9.00

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Mating Products
