M80-4711005

Datamate J-Tek DIL Female Small Bore (24-28 AWG) Crimp Connector, gold clip + gold shell, no jackscrews, 5+5 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 22
All prices are in USD
SPQ: 1		 Quantity Unit Price Ext Price Packaging
50 $7.966 $398.3 Bulk/Loose
500 $7.75 $3875 Bulk/Loose
1000 $7.11 $7110 Bulk/Loose

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderFemale
OrientationStraight
Connection TypeCable (Crimp)
Wire Size24-28 AWG
Number Of Rows2
Number Of Contacts10
Current Rating3.3A max individual contact, 3A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Jackscrew StyleNone fitted
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight1.15g
Dimensions20.00 x 5.50 x 7.50
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingCable (Crimp)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool
