M80-5112042

Datamate J-Tek DIL Male Vertical 4.5mm Throughboard Connector, selective gold + tin, with jackscrews + 5mm board mount, 10+10 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 23
All prices are in USD
SPQ: 8
Quantity Unit Price Ext Price Packaging
16 $12.434 $198.944 Tube
104 $10.532 $1095.328 Tube
504 $9.743 $4910.472 Tube
1000 $9.7 $9700 Tube


Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderMale
OrientationVertical
Connection TypePC Tail / Throughboard
Number Of Rows2
Number Of Contacts20
Current RatingDependent on mating contact
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Jackscrew StyleInternal Thread Jackscrew with Board Mount Stud and Slotted Nuts (Standard Gender)
Termination Finish100% Tin over Nickel
Housing MaterialPPS
Flammability RatingUL94V-0
Weight2.011g
Dimensions30.00 x 6.00 x 10.55
Above Board Height5.55mm
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingPC Tail / Throughboard

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required

Use with Screwdriver
