M80-5712005

Datamate J-Tek DIL Male Small Bore (24-28 AWG) Crimp Connector, gold, no jackscrews, 10+10 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 1		 Quantity Unit Price Ext Price Packaging
50 $11.77 $588.5 Bulk/Loose
100 $11.4 $1140 Bulk/Loose
250 $10.76 $2690 Bulk/Loose
500 $10.75 $5375 Bulk/Loose

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderMale
OrientationStraight
Connection TypeCable (Crimp)
Wire Size24-28 AWG
Number Of Rows2
Number Of Contacts20
Current RatingDependent on mating contact
Environmental Ratings-55°C to +125°C
Jackscrew StyleNone fitted
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight1.968g
Dimensions30.00 x 6.00 x 7.85
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingCable (Crimp)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool
