M80-6811242

Datamate L-Tek DIL Female Vertical SMT Connector, gold clip + tin shell, 6+6 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 16		 Quantity Unit Price Ext Price Packaging
112 $7.62 $853.44 Tube
512 $6.89 $3527.68 Tube

Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderFemale
OrientationVertical
Connection TypeSurface Mount (SMT)
Number Of Rows2
Number Of Contacts12
Current Rating3.3A max individual contact, 3A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Latching StyleCompatible with latches
Termination Finish100% Tin over Nickel
Housing MaterialPolyamide (Nylon) 46
Flammability RatingUL94V-0
Weight0.899g
Dimensions15.15 x 7.50 x 5.60
Above Board Height5.60mm
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingSurface Mount (SMT)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Mating Products

Articles from this product series can be use in the following assortments:
