M80-8400542

Datamate L-Tek SIL Female Vertical 3mm Throughboard Connector, gold clip + tin shell, 5 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 22
All prices are in USD
SPQ: 18
Quantity Unit Price Ext Price Packaging
108 $3.49 $376.92 Tube
126 $2.938 $370.188 Tube
504 $2.58 $1300.32 Tube
1008 $2.45 $2469.6 Tube


Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderFemale
OrientationVertical
Connection TypePC Tail / Throughboard
Number Of Rows1
Number Of Contacts5
Current Rating3.3A max individual contact, 3A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Latching StyleCompatible with latches
Termination Finish100% Tin over Nickel
Housing MaterialPolyamide (Nylon) 46
Flammability RatingUL94V-0
Weight0.367g
Dimensions13.15 max x 3.40 x 8.10
Above Board Height5.10mm
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingPC Tail / Throughboard

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Dummy Contacts
