M80-FB10868FC-0150L

Datamate J-Tek T-Contact Cable Assembly, Female Single-Ended, with 101Lok fixings, multi-color 22 AWG cable, 150mm long, 4+4 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 25
All prices are in USD
SPQ: 10		 Quantity Unit Price Ext Price Packaging
10 $50.332 $503.32 Bulk/Loose

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderFemale
OrientationStraight
Connection TypeCable Assembly
Wire Size22 AWG
Current Rating8.5A max individual contact, 3.5A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Jackscrew Style101Lok Bayonet Fixing with Slotted Head
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight4.592g
Dimensions150.00 x 18.00 x 5.50

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Insertion Removal Tool

Articles from this product series can be use in the following assortments:

Image 1 Image 1

Z80-280

 View Details

Use with Spare Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-2060005

 View Details
Image 1 Image 1

M80-FP10150L94

 View Details

Use with Dummy Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-023

 View Details

Use with Mating Products

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-5D10805MC

 View Details
Image 1 Image 1

M80-5L10842MC

 View Details
Image 1 Image 1

M80-5L10842MD

 View Details
Image 1 Image 1

M80-5S20805MD

 View Details
Image 1 Image 1

M80-5T10842MC

 View Details
Image 1 Image 1

M80-5T10842ME

 View Details

Use with Primary Alternative

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-FB10868FC-XXXXL

 View Details

Documents & Media

Component Spec

Component Spec

Download
Product Training Module

Product Training Module

Product Datasheet

Product Datasheet

Download
Web Address

Web Address

Download
