M80-FC326F1-06-XXXXL

Datamate Power Cable Assembly, Female Single Ended, hex slotted jackscrews, white 14 AWG cable, variable length (XXXXmm long), 6 contacts

Contact Sales

Download Datasheet Request Sample

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch4.00mm (0.157")
GenderFemale
OrientationStraight
Connection TypeCable Assembly
Wire Size14 AWG
Current Rating15A max per contact
Environmental Ratings-55°C to +125°C
Jackscrew StyleFloating Jackscrew with Hex Slotted Head (Standard Gender)
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Dimensions(XXXX + 0.30) x 34.00 x 5.50

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Insertion Removal Tool

Articles from this product series can be use in the following assortments:

Image 1 Image 1

Z80-290

 View Details

Use with Hoods

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-9452402

 View Details

Use with Spare Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-326

 View Details

Use with Mating Products

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-5000000M1-06-331-00-000

 View Details
Image 1 Image 1

M80-5000000M1-06-336-00-000

 View Details
Image 1 Image 1

M80-5000000M2-06-331-00-000

 View Details
Image 1 Image 1

M80-5000000M3-06-332-00-000

 View Details
Image 1 Image 1

M80-5000000M5-06-333-00-000

 View Details
Image 1 Image 1

M80-5000000M7-06-333-00-000

 View Details
Image 1 Image 1

M80-MC336M1-06-XXXXL

 View Details

Use with Primary Alternative

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-FC326F1-06-XXXXF1

 View Details

Documents & Media

Component Spec

Component Spec

Download
Product Training Module

Product Training Module

Product Datasheet

Product Datasheet

Download
Web Address

Web Address

Download

Related Products

Following products can be suitable for the assortments.

M80-4000000F1-06-326-00-000

View Details

M80-FC325F1-06-XXXXL

View Details
