Product Images

M300-2250396F2

M300 SIL Female Crimp Housing, with Hex Socket jackscrews, 3 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 18
All prices are in USD
SPQ: 1
Quantity Unit Price Ext Price Packaging
100 $4.02 $402 Bulk/Loose
250 $3.707 $926.75 Bulk/Loose
500 $3.486 $1743 Bulk/Loose
1000 $3.38 $3380 Bulk/Loose


Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeM300
Pitch3.00mm (0.118")
GenderFemale
OrientationStraight
Connection TypeCable (Crimp)
Number Of Rows1
Number Of Contacts3
Current Rating10A max per contact simultaneous
Environmental Ratings-65°C to +175°C
Jackscrew StyleFloating Jackscrew with Hex Socket Head (Standard Gender)
Housing MaterialPolyamide (Nylon) 4T
Flammability RatingUL94V-0
Weight1.32g
Dimensions21.30 x 5.30 x 12.70
End StackableNo
Mating Pin SizeØ1mm
Pcb MountingCable (Crimp)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required

Use with Hand Crimp Tool

Articles from this product series can be use in the following assortments:

Use with Positioner

Articles from this product series can be use in the following assortments:

Use with Insertion Removal Tool

Articles from this product series can be use in the following assortments:

Use with Screwdriver

Articles from this product series can be use in the following assortments:

Use with Contacts

Articles from this product series can be use in the following assortments:

Use with Primary Alternative

Articles from this product series can be use in the following assortments:
