Product Images

M50-3800842

1.27mm (0.05") Pitch DIL Male IDC Ribbon Cable Connector (DIP Transition Connector), selective gold, 8+8 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 16
All prices are in USD
SPQ: 40
Quantity Unit Price Ext Price Packaging
520 $1.99 $1034.8 Tube
1000 $1.87 $1870 Tube
2520 $1.84 $4636.8 Tube


Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyBBi
Product StatusActive
RangeARCHER
Pitch1.27mm (0.05")
GenderMale
OrientationAngled
Connection TypeCable (Ribbon IDC)
Number Of Rows2
Number Of Contacts16
Current Rating0.5A per contact
Environmental Ratings-40°C to +105°C
Termination Finish100% Tin over Nickel
Housing MaterialPBT
Flammability RatingUL94V-0
Weight0.478g
Dimensions14.36 x 3.00 x 8.20
End StackableNo
Mating Pin Size0.4mm square
Pcb MountingCable (Ribbon IDC)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required

Use with Hand Crimp Tool

Articles from this product series can be use in the following assortments:

Use with Mating Products

Articles from this product series can be use in the following assortments:

Use with Primary Alternative

Articles from this product series can be use in the following assortments:

Documents & Media

Component Spec

Component Spec

Download
Product Training Module

Product Training Module

Download
Product Datasheet

Product Datasheet

Download
Web Address

Web Address

Download
FMD

FMD

Download
