M80-4D10805F2-04-329-00-000

Datamate 2-Row Mix-Tek Female Crimp Connector, Hex Socket jackscrews, 8 x Large Bore (22 AWG) signal contacts, 4 x 20 AWG Power contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 1		 Quantity Unit Price Ext Price Packaging
50 $31.153 $1557.65 Single Pack

Product Attributes

ManufacturerHarwin
PackageSingle Pack
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm/4.00mm (0.079"/0.157")
GenderFemale
OrientationStraight
Connection TypeCable (Crimp)
Wire Size22 AWG + 20 AWG
Current RatingSignal = 3.3A max individual contact, 3A max simultaneous; Power = 5A max per contact
Environmental Ratings-55°C to +125°C
Jackscrew StyleFloating Jackscrew with Hex Socket Head (Standard Gender)
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight3.619g
Dimensions34.00 x 5.50 x 14.20

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool
