M80-4D10842F1-02-329-00-000

Datamate 2-Row Mix-Tek Female Crimp Connector, Hexagonal slotted jackscrews, 8 x Large Bore (22 AWG) signal contacts, 2 x 20 AWG Power contacts

Contact Sales

Download Datasheet Request Sample

Product Attributes

ManufacturerHarwin
PackageSingle Pack
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm/4.00mm (0.079"/0.157")
GenderFemale
OrientationStraight
Connection TypeCable (Crimp)
Wire Size22 AWG + 20 AWG
Current RatingSignal = 3.3A max individual contact, 3A max simultaneous; Power = 5A max per contact
Environmental Ratings-55°C to +125°C
Jackscrew StyleFloating Jackscrew with Hex Slotted Head (Standard Gender)
Termination Finish100% Tin over Nickel (signal), Gold (power)
Housing MaterialPPS
Flammability RatingUL94V-0
Weight2.567g
Dimensions26.00 x 5.50 x 14.20

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool
