Product Images

M80-4E10842F1

Datamate J-Tek DIL Female Extra Small Bore (28-32 AWG) Crimp Connector, gold clip + tin shell, with hex slotted jackscrews, 4+4 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 1		 Quantity Unit Price Ext Price Packaging
50 $9.763 $488.15 Bulk/Loose
500 $9.68 $4840 Bulk/Loose
1000 $8.88 $8880 Bulk/Loose

Product Attributes

ManufacturerHarwin
PackageBulk/Loose
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderFemale
OrientationStraight
Connection TypeCable (Crimp)
Wire Size28-32 AWG
Current Rating3.3A max individual contact, 3A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Jackscrew StyleFloating Jackscrew with Hex Slotted Head (Standard Gender)
Termination Finish100% Tin over Nickel
Housing MaterialPPS
Flammability RatingUL94V-0
Weight1.625g
Dimensions18.00 x 5.50 x 8.50

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M22520/2-01

 View Details

Use with Positioner

Articles from this product series can be use in the following assortments:

Image 1 Image 1

T5747

 View Details

Use with Insertion Removal Tool

Articles from this product series can be use in the following assortments:

Image 1 Image 1

Z80-280

 View Details

Use with Hoods

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-9450802

 View Details

Use with Spare Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-0190001

 View Details

Use with Dummy Contacts

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-023

 View Details

Use with Mating Products

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-5000842

 View Details
Image 1 Image 1

M80-5020842

 View Details
Image 1 Image 1

M80-5100842

 View Details
Image 1 Image 1

M80-5120842

 View Details
Image 1 Image 1

M80-5300842

 View Details
Image 1 Image 1

M80-5320842

 View Details
Image 1 Image 1

M80-5400842

 View Details
Image 1 Image 1

M80-5420842

 View Details
Image 1 Image 1

M80-5600805

 View Details
Image 1 Image 1

M80-5610805

 View Details

Use with Primary Alternative

Articles from this product series can be use in the following assortments:

Image 1 Image 1

M80-4E10805F1

 View Details
