M80-4T10601F2-04-321-00-000

Datamate 2-Row Mix-Tek Female Vertical Throughboard Connector, Hex Socket jackscrews, 6 x 3mm Throughboard signal contacts, 4 x 3.5mm Throughboard Power contacts

Download Datasheet Request Sample
In-Stock: 32
Factory Lead Time (wks): 27
All prices are in USD
SPQ: 1
Quantity Unit Price Ext Price Packaging
56 $37.33 $2090.48 Tube
104 $35.26 $3667.04 Tube
256 $34.24 $8765.44 Tube


Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm/4.00mm (0.079"/0.157")
GenderFemale
OrientationVertical
Connection TypePC Tail / Throughboard
Number Of RowsMixed
Number Of Contacts6
Current RatingSignal = 3.3A max individual contact, 3A max simultaneous; Power = 20A max per contact
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 235°C for 5 seconds
Jackscrew StyleFloating Jackscrew with Hex Socket Head (Standard Gender)
Termination FinishTin/Lead (signal), Gold (power)
Housing MaterialPPS
Flammability RatingUL94V-0
Weight2.11g
Dimensions32.00 x 5.50 x 9.00
Above Board Height5.50mm
End StackableNo
Mating Pin SizeØ0.5mm (signal)
