M80-4TE2042F3

Datamate J-Tek DIL Female Extended Height Vertical 3mm Throughboard Connector, gold clip + tin shell, guide pin with 5mm board mount jackscrews, 10+10 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 9		 Quantity Unit Price Ext Price Packaging
108 $28.4 $3067.2 Tube
126 $24.247 $3055.122 Tube

Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderFemale
OrientationVertical
Connection TypePC Tail / Throughboard
Number Of Rows2
Number Of Contacts20
Current Rating3.3A max individual contact, 3A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Jackscrew StyleGuide Pin with Board Mount Stud (Standard Gender)
Termination Finish100% Tin over Nickel
Housing MaterialPPS
Flammability RatingUL94V-0
Weight6.046g
Dimensions30.00 x 5.50 x 20.70
Above Board Height15.70mm
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingPC Tail / Throughboard

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Accessory
