M80-8370742

Datamate L-Tek SIL Male Horizontal SMT Connector, unlatched, selective gold + tin, 7 contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 14
Quantity Unit Price Ext Price Packaging
112 $4.77 $534.24 Tube
126 $3.477 $438.102 Tube
1008 $3.46 $3487.68 Tube
2506 $3.22 $8069.32 Tube


Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm (0.079")
GenderMale
OrientationHorizontal
Connection TypeSurface Mount (SMT)
Number Of Rows1
Number Of Contacts7
Current Rating3.3A max individual contact, 3A max simultaneous (25°C)
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Latching StyleNone
Termination Finish100% Tin over Nickel
Housing MaterialPPS
Flammability RatingUL94V-0
Weight0.593g
Dimensions17.60 x 7.50 x 3.85
Above Board Height3.85mm
End StackableNo
Mating Pin SizeØ0.5mm
Pcb MountingSurface Mount (SMT)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required
