M80-MV311M2-06

Datamate Coax Plug (Male) Vertical Throughboard Connector, Jackscrews + 3.5mm board mount, no signal contacts, 6 x 3mm Throughboard Coax contacts

Download Datasheet Request Sample

Factory Lead Time (wks): 22
All prices are in USD
SPQ: 7
Quantity Unit Price Ext Price Packaging
7 $72.6 $508.2 Tube
56 $66.25 $3710 Tube


Product Attributes

ManufacturerHarwin
PackageTube
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch4.00mm (0.157")
GenderMale
OrientationVertical
Connection TypePC Tail / Throughboard
Number Of Rows1
Current Rating0.5A per contact
Environmental Ratings-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Jackscrew StyleInternal Thread Jackscrew with Board Mount Stud (Standard Gender)
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight1.971g
Dimensions34.00 x 6.00 x 9.05
Above Board Height5.55mm
End StackableNo
Pcb MountingPC Tail / Throughboard

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Screwdriver

Articles from this product series can be use in the following assortments:

Use with Hoods

Articles from this product series can be use in the following assortments:

Use with Accessory

Articles from this product series can be use in the following assortments:

Use with Primary Alternative

Articles from this product series can be use in the following assortments:
