S1941-46R

Multi-Directional SMT Spring Contact (also known as Grounding Contact or Shield Finger), 7.25mm high, tin, Tape & Reeled

Download Datasheet Request Sample
In-Stock: 2450
Factory Lead Time (wks): 23
All prices are in USD
SPQ: 350
Quantity Unit Price Ext Price Packaging
2450 $0.217 $531.65 Tape and Reel
4900 $0.207 $1014.3 Tape and Reel
9800 $0.196 $1920.8 Tape and Reel
24850 $0.195 $4845.75 Tape and Reel


Product Attributes

ManufacturerHarwin
PackageTape and Reel
Product FamilyEZi
Product StatusActive
RangeSPRING CONTACTS
OrientationVertical and Horizontal
Connection TypeSurface Mount (SMT)
Current Rating9A max
Operating Temperature-55°C to +125°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Termination Finish100% Tin over Nickel
Weight0.127g
Dimensions9.59 x 5.70 x 7.25
Above Board Height7.25mm
Pcb MountingSurface Mount (SMT)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required

Use with Primary Alternative
