S70-125161545R

Surface Mount Contact Pad, flat, 2.5mm x 1.6mm rectangle, 0.15mm thick, Tape & Reeled

Download Datasheet Request Sample

Factory Lead Time (wks): 16
All prices are in USD
SPQ: 4000
Quantity Unit Price Ext Price Packaging
12000 $0.194 $2328 Tape and Reel
24000 $0.193 $4632 Tape and Reel


Product Attributes

ManufacturerHarwin
PackageTape and Reel
Product FamilyEZi
Product StatusActive
RangePOGOPINS
Current Rating6A
Environmental Ratings-40°C to +180°C
Soldering DataMax Solder Temperature: 260°C for 10 seconds
Termination FinishGold
Weight0.006g
Dimensions2.50 x 1.60 x 0.15
Above Board Height0.15mm

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with no Exemption required

Use with Primary Alternative

Articles from this product series can be use in the following assortments:
