M80-4D10205F1-00-000-04-327

Datamate 2-Row Mix-Tek Female Crimp Connector, Hexagonal slotted jackscrews, 2 x Large Bore (22 AWG) signal contacts, 4 x 16 AWG Power contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 1		 Quantity Unit Price Ext Price Packaging
25 $28 $700 Single Pack
50 $26.24 $1312 Single Pack
100 $25.37 $2537 Single Pack
250 $23.97 $5992.5 Single Pack

Product Attributes

ManufacturerHarwin
PackageSingle Pack
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm/4.00mm (0.079"/0.157")
GenderFemale
OrientationStraight
Connection TypeCable (Solder + Crimp)
Wire Size22 AWG + 16 AWG
Number Of RowsMixed
Number Of Contacts2
Current RatingSignal = 3.3A max individual contact, 3A max simultaneous; Power = 10A max per contact
Environmental Ratings-55°C to +125°C
Jackscrew StyleFloating Jackscrew with Hex Slotted Head (Standard Gender)
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight3.139g
Dimensions28.00 x 5.50 x 13.00
End StackableNo
Mating Pin SizeØ0.5mm (signal)

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool
