M80-5D10405M3-00-000-02-337

Datamate 2-Row Mix-Tek Male Crimp Connector, Jackscrews + 3.5mm front panel mount, 4 x Large Bore (22 AWG) signal contacts, 2 x 16 AWG Power contacts

Download Datasheet Request Sample

Factory Lead Time (wks): TBA
All prices are in USD
SPQ: 1		 Quantity Unit Price Ext Price Packaging
50 $29.32 $1466 Single Pack
100 $28.34 $2834 Single Pack
250 $26.78 $6695 Single Pack

Product Attributes

ManufacturerHarwin
PackageSingle Pack
Product FamilyHRi
Product StatusActive
RangeDatamate
Pitch2.00mm/4.00mm (0.079"/0.157")
GenderMale
OrientationStraight
Connection TypeCable (Solder + Crimp)
Wire Size22 AWG + 16 AWG
Current RatingSignal = 3.3A max individual contact, 3A max simultaneous; Power = 10A max per contact
Environmental Ratings-55°C to +125°C
Jackscrew StyleInternal Thread Jackscrew with Front Panel Mount Stud and Slotted Nuts (Standard Gender)
Termination FinishGold
Housing MaterialPPS
Flammability RatingUL94V-0
Weight2.664g
Dimensions22.00 x 6.00 x 12.70

Environmental and Export

Rohs StatusRoHS Compliant (2015/863/EU) with Exemption 6c

Use with Hand Crimp Tool
