Harwin USB-C Connectors: IPX8 Protection for Demanding Designs

Harwin Asia expands its high-performance interconnect range with the introduction of the USB-C Waterproof Connector Series, engineered to deliver power, data, and reliability in one compact interface. Designed for industrial, automotive, and consumer applications, these connectors provide dependable USB-C connectivity while maintaining IPX8-rated waterproof protection, ensuring performance even in harsh or outdoor environments.



Key Features

✅ IPX8 Waterproof Protection – Built to resist water ingress for secure performance in challenging conditions.
✅ High-Speed Data Transmission – Supports USB 2.0, USB 3.2, and USB 4.0 standards with data rates up to 40 Gbps.
✅ Power Delivery Ready – Handles up to 10 A and 30 V DC for fast charging and high-power applications.
✅ Reversible Type-C Design – Enables easy plug-in from any orientation for user convenience.
✅ Durable Construction – Rated for up to 10,000 mating cycles for long service life.
✅ Flexible Mounting Options – Available in SMT, DIP, and hybrid configurations to fit various PCB layouts.



Product Range



Application & Market

The Harwin USB-C Waterproof Series is ideal for:

• Consumer Electronics – Laptops, tablets, portable devices, and docking systems

• Industrial Equipment – Control systems, diagnostic tools, and automation modules

• Automotive & EV – Onboard electronics, infotainment, and charging interfaces

• Outdoor IoT Devices – Smart sensors and connected equipment exposed to the elements

• Medical & Instrumentation – Portable diagnostic and monitoring devices



Summary

Combining rugged waterproof protection with high-speed performance, Harwin’s USB-C Waterproof Connector Series provides a robust solution for designs that demand reliability under all conditions. Whether used in industrial automation, automotive systems, or next-generation IoT devices, these connectors ensure your connection stays secure — rain or shine.



Embedded Antennas: Compact Performance for Reliable Wireless Connectivity

Harwin’s Embedded Antennas deliver compact, high-performance wireless solutions for applications where space is limited but connectivity is critical. Designed for integration into PCBs or enclosures, these antennas support multiple wireless standards — providing exceptional signal performance and design flexibility.



Key Features

✅ Compact form factor – ideal for space-limited designs
✅ Multi-band support for GNSS, LTE, GSM, Wi-Fi, Bluetooth, ISM & LoRa
✅ Variety of mounting options including LDS and ceramic bases
✅ Pre-configured designs for reduced assembly time
✅ 50Ω impedance for consistent RF performance
✅ RoHS & REACH compliant for global standards



Product Range

• LDS & Ceramic Antennas – MMANT-1000X, MMANT-1600X

• PCB & Flexible PCB Antennas – MMANT-1200X, MMANT-1500X



Applications & Market

Harwin’s Embedded Antennas are trusted across a variety of industries that require compact, integrated wireless connectivity:
📱 Consumer Electronics – smartphones, wearables, smart home devices
🚗 Automotive & Transportation – telematics, GPS systems, infotainment modules
🏭 Industrial IoT & Automation – wireless monitoring and smart sensors
🌆 Smart City & Infrastructure – public safety networks, asset tracking systems
💉 Medical & Healthcare – diagnostic devices and patient monitoring
⚡ Energy & Utilities – smart meters and energy management systems



Summary

Compact yet powerful, Harwin’s Embedded Antennas deliver optimized performance and design versatility for next-generation connected systems. Whether in IoT devices, medical equipment, or industrial applications, these antennas ensure stable signal transmission and long-term reliability within confined spaces.



Harwin USB Type-C Connector Solutions

High-Speed Transmission · Reliable Power

Harwin’s USB Type-C High-Speed Transmission series delivers next-generation data and power connectivity in a compact, reversible design.
Supporting USB 2.0, 3.2, and 4.0 standards, it offers up to 40Gbps data transfer and 10A / 30V DC power delivery.
With multiple mounting options and 10,000 mating cycles, these connectors ensure reliable and flexible performance across applications.



Key Features

✅ Supports USB 2.0 / 3.2 / 4.0 – up to 40Gbps high-speed data transfer
✅ Power Delivery Ready – up to 10A / 30V DC
✅ Durable – rated for 10,000 mating cycles
✅ Reversible plug-in design for easy connection
✅ Multiple mounting options: SMT, DIP, Hybrid
✅ Operating temperature: -40°C to +85°C



Product Range

• High-Speed Transmission Series – MMUSBC40F, MMUSBC40M
• USB 3.2 Series – MMUSBC32F, MMUSBC32M



Applications & Market

Harwin’s USB Type-C connectors are trusted in applications that demand fast, efficient, and reliable connectivity:
💻 Consumer Electronics – laptops, tablets, docking stations
🚗 Automotive & EV – diagnostic tools, infotainment systems, charging interfaces
🏭 Industrial Equipment – control systems, automation tools
🌐 Telecommunications & Networking – routers, modems, and gateways



Summary

Compact and durable, Harwin’s USB Type-C connectors provide high-speed data transmission and robust power delivery for next-generation systems.
Designed for performance and reliability, they ensure long-lasting connectivity across a wide range of industries and devices.



Datamate J-Tek: Reliable Connections for Satellite Video Transmission

Compact, secure interconnects for demanding space applications

When it comes to satellite communications, reliability is non-negotiable. Harwin’s Datamate J-Tek connectors deliver trusted performance for video transmission systems in geostationary satellites, ensuring uninterrupted operation in one of the harshest environments possible.

Key Features

✅ Proven 2mm pitch high-reliability connector system
✅ Female guide pins & male panel-mount options for secure alignment
✅ Robust jackscrew locking to withstand vibration and shock
✅ Cable-to-cable and panel-mount configurations
✅ Lightweight and compact for space-constrained enclosures

Proven in Satellite Video Transmission

Harwin’s J-Tek connectors are successfully used in satellite TV systems from geostationary orbit.
Customer systems integrate enclosed server units within the satellite body, connected with J-Tek cable assemblies featuring female guide pins and male panel-mount configurations.
This solution ensures stable, high-quality video transmission and reliable performance throughout satellite operations.

Applications & Markets

🌍 Space & Satellite Systems – video, communication, and control systems
📡 Defense & Aerospace – mission-critical data transfer
⚡ Industrial & Robotics – high-vibration environments
🔒 Secure Electronics – where compact, high-reliability connections are needed

Summary

With a proven record in satellite video transmission, Harwin’s Datamate J-Tek connectors demonstrate the robustness and versatility needed for extreme environments. From geostationary orbit to ground-based mission-critical applications, J-Tek ensures secure, lightweight, and reliable connectivity.



External Antenna Solutions: Stubby & Whip Antennas

Harwin’s MMi External Antennas are designed to deliver clear signals and dependable coverage for a wide range of wireless communication protocols. Compact and rugged, these antennas are built to integrate seamlessly into space-sensitive designs while maintaining reliable connectivity in demanding environments.

Key Features

✅ Multi-band support including Wi-Fi, LTE, 5G, GNSS & Bluetooth
✅ Compact designs with flexible mounting options
✅ SMA hinge connectors for reliable, secure connections
✅ IP66/67 rated options for dust & water resistance
✅ High-gain performance for extended signal reach

Product Range

• Stubby Antenna – Low-profile, compact design ideal for space-saving installs, with Wi-Fi coverage (2.4 / 5 / 6 GHz) and IP66 protection.

• Whip Antenna – LTE + Wi-Fi coverage, SMA hinge connector for flexible mounting, higher gain for stronger signal reach.

Applications & Markets

Harwin’s Stubby and Whip antennas are trusted across industries that demand reliable wireless performance:
✔️ Telecommunications & Networking – routers, gateways, access points
✔️ Automotive & Telematics – in-vehicle Wi-Fi and tracking
✔️ Industrial IoT & Automation – wireless monitoring in harsh conditions
✔️ Public Safety & Transportation – robust connectivity for mission-critical systems

Summary

From space-saving Stubby antennas to high-gain Whip antennas, Harwin’s external antenna solutions provide versatile options for reliable wireless connectivity. Designed for modern wireless standards and rugged enough for challenging environments, they deliver clear signals and better coverage where it matters most.



Datamate J-Tek: Extended Height, Reliable Connections

Product in Action: Passenger Service Unit

Engineered for aerospace, defense, and industrial platforms, Harwin’s Datamate J-Tek Extended Height connectors deliver proven reliability with extra board stacking space. Designed to handle vibration, shock, and space-limited assemblies, they offer trusted performance where durability matters most.

Key Features

✅ Extended height for larger components and cable routing
✅ Stainless steel guide pins for secure mating
✅ Robust board-mount studs for strain relief under vibration
✅ Shrouded and polarized contacts for error-free connections
✅ Compliant with BS 9525-F0033 and CECC 75101-008 standards

Proven in Passenger Service Units

Datamate J-Tek connectors are trusted in commercial aviation cabins, powering Passenger Service Units (PSUs) that deliver lighting, ventilation, and passenger controls. With vibration-resistant fixings and reliable endurance, they ensure uninterrupted service across long-term operation.

Product Range

Available in female extended height connectors:

• 10 contacts (5+5) – M80-4TE1042F3 / M80-4TE1005F3

• 20 contacts (10+10) – M80-4TE2042F3 / M80-4TE2005F3

• 30 contacts (15+15) – M80-4TE3042F3 / M80-4TE3005F3

Compatible male connectors include the M80-500, M80-510, M80-511 (throughboard) and M80-502, M80-512, M80-513 (SMT).

Applications & Markets

🔹 Aerospace & Avionics
🔹 Military & Defense Systems
🔹 Robotics & Industrial Automation
🔹 Oil & Gas Equipment
🔹 Autosport Electronics

Summary

With higher board stacking, rugged strain relief, and field-proven reliability, Datamate J-Tek Extended Height connectors are the dependable choice for vibration-heavy and space-constrained environments.
