Compact Board-to-Board Connectivity for High-Speed PCB Designs

Harwin Archer .5 and Archer .8 provide compact high pin count mezzanine connector solutions for high-speed signal and data transfer in industrial and embedded electronics applications.

As electronic designs become smaller and more complex, engineers need board-to-board connector solutions that can support reliable signal transfer without taking up unnecessary PCB space. Harwin Archer .5 and Archer .8 are compact mezzanine connectors designed for daughterboard-to-motherboard signal transfer in high-density PCB layouts.

The Archer .5 range is based on a 0.5 mm pitch and supports data rates up to 8 GHz / 16 Gb/s, while Archer .8 is based on a 0.8 mm pitch and supports data rates up to 12 GHz / 24 Gb/s. Both options are suitable for compact board-to-board designs where high-speed communication, contact density, and assembly reliability are important.

Key Features:

• Compact mezzanine connection design
  Supports board-to-board signal transfer between daughterboard and motherboard layouts.


• Pitch options for PCB design flexibility
  Available in 0.5 mm pitch for Archer .5 and 0.8 mm pitch for Archer .8.


• High-speed data transfer support
  Archer .5 supports up to 8 GHz / 16 Gb/s, while Archer .8 supports up to 12 GHz / 24 Gb/s.


• High contact density
  Available with up to 120 contacts in a double-row layout.


• SMT assembly ready
  Supplied in tape and reel for high-volume surface mount assembly.


• Polarized housing design
  Helps support error-free assembly and correct mating orientation.


• Gull-wing SMT terminations
  Allows easier solder inspection during PCB assembly.


• Compliance support
  Halogen-free, RoHS compliant, and free of REACH SVHC materials according to the datasheet.


Application and Market

Harwin SMT Cable Clips are suitable for electronic equipment where cable routing, wire retention, and compact PCB-level c

Harwin Archer .5 and Archer .8 are suitable for compact electronics applications requiring high-speed board-to-board signal connections, including:

• Embedded computing
• Building automation
• Smart metering
• IoT modules

These applications often require compact interconnect solutions that can support data transfer between stacked PCBs or removable modules while maintaining efficient use of PCB space.

Engineering Background:

Mezzanine connectors are commonly used when two PCBs need to be connected in a stacked board configuration. This helps designers route signals between a motherboard and a daughterboard while keeping the overall assembly compact.

For high-speed electronics, connector selection should consider more than pitch alone. Engineers may need to review data rate, board-to-board height, contact count, temperature range, mechanical durability, and assembly requirements.

According to the Archer datasheet, Archer .5 offers a smaller 0.5 mm pitch with 8 mm board-to-board height, while Archer .8 offers 0.8 mm pitch with 5 mm board-to-board height. Archer .8 also supports the higher listed data rate of up to 12 GHz / 24 Gb/s and a wider upper operating temperature of +125°C.



Harwin Solution

Harwin Archer .5 and Archer .8 offer two compact high-speed mezzanine connector options within the BBi range.

Archer .5 is suited for compact high-density board-to-board designs requiring a smaller 0.5 mm pitch connector solution. It supports data rates up to 8 GHz / 16 Gb/s and is designed for compact signal transfer applications.

Archer .8 provides a 0.8 mm pitch option with data rates up to 12 GHz / 24 Gb/s. It offers a 5 mm board-to-board height and an operating temperature range of -40°C to +125°C, making it suitable for compact high-speed industrial applications where these specifications are required.

Both ranges are designed with polarized housings, SMT compatibility, tape and reel packaging, and board-to-board mating support for high-volume electronics assembly.



Download Harwin Archer .5 & Archer .8 Datasheet

Access the Archer .5 and Archer .8 datasheet to compare pitch, data rate, board-to-board height, operating temperature, materials, mechanical details, and product category information.

👉 Fill in the form below to download the Harwin Archer .5 & Archer .8 Datasheet.
Your download will be available immediately after submission.

Download Now

Need more information?
Contact Us | Request Sample

Summary

Harwin Archer .5 and Archer .8 are compact high pin count mezzanine connectors designed for high-speed board-to-board signal transfer. With 0.5 mm and 0.8 mm pitch options, data rates up to 16 Gb/s for Archer .5 and 24 Gb/s for Archer .8, and SMT assembly-ready designs, the Archer range supports compact PCB applications across embedded computing, building automation, smart metering, and IoT modules.

View Product

Why Are There Different FPC Locking Mechanisms?

Designed to Support Different PCB Layout and Assembly Requirements.

Flexible Printed Circuit connectors provide a compact method of connecting flexible circuits to printed circuit boards where available space, connector orientation, and cable routing must be carefully considered.

Selecting an FPC connector is not only about choosing the correct pitch. The locking mechanism, contact orientation, connector height, cable thickness, and insertion direction can all influence how easily the connector fits into the PCB layout and assembly process.

The Harwin Solutions FPC Connector Range includes multiple locking mechanisms, contact configurations, and fine-pitch options, allowing engineers to compare connector styles according to their specific mechanical and PCB design requirements.



Key Features:

✔ Available in 0.30 mm and 0.50 mm pitch options
✔ Front Flip Lock, Back Flip Lock, and Slide Lock actuator types
✔ Bottom Contact, Upper Contact, and Dual Contact configurations
✔ Low-profile SMT designs for compact PCB assemblies
✔ Multiple connector heights and compatible cable thickness options
✔ Rated up to 50 V and 0.5 A, depending on model
✔ Individual technical drawings available for each part number

Application and Market

Harwin Solutions FPC Connectors are suitable for electronic designs that require compact board-to-flex connections, including:

✔ Display and interface modules
✔ Embedded electronic devices
✔ Control boards
✔ Portable electronic equipment
✔ Compact PCB assemblies
✔ Electronic modules using flexible printed circuits

The suitability of each connector depends on the selected part number, cable orientation, PCB layout, and overall system requirements.

Engineering Background:

Different PCB layouts do not always provide the same level of access around the connector. In some designs, the flexible cable may need to be inserted from the front, while other layouts may require access from the opposite side or a sliding actuator due to surrounding components and limited mechanical space.

• Front Flip Lock connectors use an actuator that opens from the front, providing direct access for FPC insertion.
• Back Flip Lock connectors open from the opposite side, offering an alternative assembly direction where rear access is preferred.
• Slide Lock connectors use a sliding actuator to secure the flexible circuit after insertion, providing another option for designs where a flip-style actuator may not suit the available layout.

Understanding these differences helps engineers evaluate which locking mechanism, contact position, and connector orientation best fits the intended PCB design.



Harwin Solution

The Harwin Solutions FPC Connector Range provides multiple connector configurations for compact PCB and flexible circuit designs.

With Front Flip Lock, Back Flip Lock, and Slide Lock options, together with Bottom, Upper, and Dual Contact configurations, engineers can compare different connector styles according to their required cable direction, assembly access, and board layout.

The range also includes 0.30 mm and 0.50 mm pitch options, multiple product heights, and different cable thickness requirements. Individual technical drawings are available for each part number to support connector evaluation and mechanical design review.



Access the Harwin Solutions FPC Technical Drawing

Access key product information, including available part numbers, pitch options, product heights, actuator types, rated current, contact configurations, cable thickness requirements, and individual technical drawings to help you identify a suitable FPC connector for your PCB design.

👉 Fill in the form below to access the Harwin Solutions FPC Technical Drawing.

Access Now

Need more information?
Contact Us | Request Sample

Summary

Choosing the appropriate FPC connector involves more than selecting the correct pitch. Locking mechanism, actuator direction, contact orientation, connector height, and cable thickness can all affect PCB layout and assembly.

By offering multiple locking styles and contact configurations, the Harwin Solutions FPC Connector Range provides engineers with greater flexibility when designing compact board-to-flex connections.

View Product

Reliable Interconnect Solutions for Mission-Critical Vision Systems

Discover how Harwin Datamate, Gecko, and M300 connector families supported a panoramic vision system designed for military vehicles operating in severe shock and vibration environments.

Modern military vehicles rely on panoramic vision systems to support situational awareness and other demanding operational requirements. These systems require dependable power and data connections, particularly when the equipment is exposed to shock, vibration, and harsh operating conditions.

In this Products in Action case study, Harwin connector solutions were selected for a next-generation panoramic vision system control unit. Datamate, Gecko, and M300 provided rugged connections, while pre-made cable assemblies helped ease the production process.

Key Features

• Rugged connector families for demanding environments
• Reliable power and data connectivity
• Supports panoramic vision system control units
• Suitable for applications exposed to severe shock and vibration
• Pre-made cable assemblies help simplify production



Application and Market

• Military vehicles
• Panoramic vision systems
• Electro-optical systems
• Surveillance and observation equipment
• Defense mission electronics
• Rugged embedded systems



Engineering Background

Modern panoramic vision systems used in military vehicles require reliable power and data connectivity to support camera control actuators operating in demanding environments. As these systems are exposed to severe shock and vibration, interconnect solutions must maintain dependable electrical performance while withstanding continuous mechanical stress.

For engineers designing rugged defence electronics, selecting high-reliability connectors is an important consideration to help ensure stable system operation while supporting efficient production and assembly.

Harwin Solution

Harwin Datamate, Gecko, and M300 connector families were used to provide rugged connections within the panoramic vision system control unit. Pre-made cable assemblies also helped ease the production process.

The source material identifies the connector families used but does not specify individual part numbers.

Download the Harwin Defense Application Brochure

Explore Harwin interconnect solutions for demanding defense applications, including military vehicles, rugged electronic systems, vision platforms, and other harsh-environment designs.

Complete the form to download the Harwin Defense Application Brochure

Download Now

Need more information?
Contact Us | Request Sample



Summary

Military vehicle vision systems require reliable power and data connections to support camera control actuators in environments exposed to severe shock and vibration.

Harwin Datamate, Gecko and M300 connector families provide rugged interconnect solutions, while pre-made cable assemblies help simplify production and assembly.

Reliable vision systems start with reliable interconnects.

View Product

Reliable Cable & Connector Solutions for EV Charging Applications

Explore Hotron EV charging cable and connector solutions designed to support AC charging, DC fast
charging, high-power charging, and EV infrastructure requirements.

As EV charging infrastructure continues to expand, reliable cable and connector solutions are essential for supporting stable power transmission across different charging environments. From residential charging to public charging stations and high-power fast charging systems, each application requires the right combination of cable design, connector type, current rating, voltage level, and regional standard compliance.

Hotron provides a wide range of EV charging solutions, including AC charging cables, DC charging cables, AC charging connectors, DC charging connectors, NACS charging connector options, and High Power Charging cable solutions. The brochure also covers EV charging modes, cable characteristics, regional approvals, PV cable solutions, PV junction box options, photovoltaic extension lines, and energy storage cables.

Key Features

✅ AC and DC charging cable solutions
✅ AC and DC charging connector options
✅ NACS charging connector support
✅ High Power Charging cable solutions
✅ Regional standards and approval coverage
✅ Customer-specific cable and connector solutions available
✅ PV cable solutions and energy storage cable options
✅ Suitable for different EV charging modes and infrastructure requirements



Applications & Markets

Hotron EV Charging Solutions are suitable for a wide range of EV and energy-related applications, including:

✔ Residential EV charging
✔ Public charging stations
✔ DC fast charging infrastructure
✔ High-power charging systems
✔ EV charging equipment and charging piles
✔ Solar / photovoltaic systems
✔ Energy storage systems
✔ EV infrastructure and mobility projects

Download the Hotron EV Charging Solutions Brochure

Access detailed product information, cable and connector options, charging mode references, technical parameters, and application guidance to better understand Hotron’s EV charging, PV, and energy storage cable solutions.

Complete the form below to access Hotron EV Charging Solution Brochure and explore suitable options for your next project.

Download Brochure Now

Need more information?
Request a Sample | Contact Sales



Summary

Hotron EV Charging Cable & Connector Solutions support AC charging, DC fast charging, NACS charging connector options, and high-power charging applications. With regional standard coverage, custom solution availability, and additional support for PV and energy storage cable applications, Hotron provides reliable connectivity solutions for modern EV charging and renewable energy infrastructure.



View Product

From POS Terminals to Smart Payment Systems

Compact SMT cable clips for organized wire routing in space-constrained electronic designs.

As electronic devices become smaller and more integrated, cable management remains an important part of PCB and equipment design. In compact payment hardware, POS terminals, kiosks, and embedded electronics, small internal wires need to be routed neatly, kept close to the PCB, and managed in a way that supports efficient final assembly.

Harwin SMT Cable Clips provide a compact surface-mount cable management solution for individual wires and cables. Designed for PCB-level cable retention, these clips help organize cable runs while supporting automated assembly processes.

Key Features:

• Compact SMT cable management solution – Designed to help manage wires and cables directly on or near the PCB.
• Available in 5 sizes – Supports cable management for multiple cables from 0.9mm up to 3mm diameter.
• Small footprint and low profile – The smallest clip have a footprint of 5.5mm × 4.5mm and a height of only 1.5mm.
• Dual beam metal design – Provides secure and flexible cable retention, with a large lead-in to make cable installation easier.
• Tin-plated finish – Supports solderability and provides resistance to long-term corrosion.
• Tape and reel packaging – Suitable for automated SMT assembly and soldering with other SMT components.
• Supports coax grounding applications – Metal construction can provide direct electrical connection from coax screening braid to PCB ground plane in suitable designs.



Application and Market

Harwin SMT Cable Clips are suitable for electronic equipment where cable routing, wire retention, and compact PCB-level cable management are required.

Target applications include:

• Banking POS terminals
• Smart payment devices
• Self-service kiosks
• Retail checkout systems
• Compact handheld devices
• Communications equipment
• Medical electronics
• Robotics
• Avionics controls
• Compact electronic modules and assemblies

Engineering Background:

Compact electronic equipment often includes internal wires or cables that must be routed neatly within limited space. If wires are left unmanaged, they may become trapped, snag on PCB components, or make final assembly and maintenance more difficult.

Key design considerations:

• Limited PCB space – Compact devices need low-profile cable management that does not take up unnecessary board area.
• Cable routing control – Wires may need to be kept close to the PCB to support organized internal layouts.
• Assembly efficiency – Manual fitting of traditional plastic clips can add handling steps during production.
• Cable retention – A secure clip design helps hold wires in place and reduce unnecessary movement.
• Application flexibility – Different wire diameters and cable quantities may require different clip sizes.



Harwin Solution

Harwin SMT Cable Clips provide a compact metal cable retention solution for PCB-level wire management. Unlike traditional plastic cable clips, these parts are surface-mount components and can be assembled with the rest of the SMT process.

Solution highlights:

• SMT-mounted cable retention – Allows clips to be placed and soldered with other SMT components.
• Low-profile design – Suitable for confined PCB spaces and compact electronic assemblies.
• Multiple cable size options – The range supports different cable diameters and cable quantities.
• Dual beam retention – Helps hold wires securely while allowing easier cable insertion.
• Reduced manual handling – Tape and reel packaging supports automated placement, reducing the need for separate hand-fitted plastic clips.
• Cleaner internal layout – Helps keep cables organized and close to the PCB for easier equipment assembly.



Download Harwin SMT Cable Clips Product Guide

Explore product information, cable size options, part number capacity table, application details, and SMT cable management benefits.

Your download will be available immediately after submission

👉 Fill in the form below to download the Harwin SMT Cable Clips Product Guide.

Download Now

Need more information?
Contact Us | Request Sample

Summary

From traditional POS terminals to modern smart payment systems, compact electronic devices continue to require clean and organized internal cable routes. Harwin SMT Cable Clips provide a compact SMT-mounted solution to help keep wires close to the PCB, support cable retention, and simplify cable management in space-constrained electronic assemblies.

View Product

Rugged, Environmentally Sealed Power Connectivity for Industrial Applications

Built to help protect industrial power connections from dust, water ingress, and harsh operating conditions.

Harwin Indess C90 Industrial Circular Power Connectors are designed to support reliable power connectivity in harsh and demanding environments. Built with rugged construction and environmentally sealed performance, this connector range provides a dependable solution for industrial applications where dust, water exposure, and mechanical durability are key design considerations.

The C90 range includes multiple connector body styles and contact configurations, giving engineers flexibility when designing cable-to-cable or cable-to-panel power connections.

Key Features:

Environmentally Sealed
Harwin C90 Industrial Circular Power Connectors are fully environmentally sealed when mated, with sealing that exceeds IP67. This helps protect the connection against dust and water ingress in demanding environments.

Reliable Power Performance
The C90 range supports up to 13A current rating and voltage ratings up to 500V AC / 700V DC, making it suitable for industrial power connection applications.

Flexible Contact Options
Available in 2, 3, 4, or 6 contact configurations, the range gives engineers flexibility to select a connector option that fits different system requirements.

Multiple Connector Styles
The range includes Straight Plug, Cable Connector, and Panel Mount Receptacle options, supporting both cable-to-cable and cable-to-panel connection designs.

Built for Industrial Applications
With rugged aluminium shells, silver-plated copper alloy contacts, and synthetic rubber gaskets, the C90 range is designed for repeated use and dependable performance in industrial environments.

Application and Market

Harwin Indess C90 Industrial Circular Power Connectors are suitable for applications that require robust power connections in harsh or demanding environments.

Typical applications and markets include:

• Industrial machinery
• Outdoor signalling
• Robotic control systems
• Wireless base stations
• Construction vehicles
• Power supply systems
• Cable-to-panel industrial connections
• Harsh environment equipment



Engineering Background:

In industrial environments, power connectors may be exposed to dust, moisture, repeated mating, cable strain, and mechanical stress. These conditions can affect connection reliability if the connector is not designed with suitable sealing, durability, and cable protection.

For engineers, connector selection is not only about current and voltage rating. Other factors such as ingress protection, contact count, body style, termination method, mating durability, and accessory support also play an important role in long-term system performance.

Harwin’s C90 Industrial Circular Power Connectors address these requirements by combining environmental sealing, rugged connector construction, flexible contact options, and accessory support for demanding industrial power designs.



Harwin Solution

The Harwin Indess C90 range provides a rugged circular power connector solution for industrial systems requiring reliable power connectivity in harsh environments.

The range offers Straight Plug, Cable Connector, and Panel Mount Receptacle body styles, giving designers options for cable-to-cable and cable-to-panel connections. Pin and socket contact options are available across the body styles, supporting flexible design configurations.

For additional protection, rubber bushings provide cable bend support and help complete rear sealing, while dust caps protect the connector interface from water and dust when the connector is not in use.

With sealing that exceeds IP67, up to 13A current rating, voltage ratings up to 500V AC / 700V DC, and multiple contact configurations, Harwin C90 Industrial Circular Power Connectors provide a practical solution for demanding industrial power applications.



Download the Industrial Circular Power Connectors Product Training Module

Explore the Harwin C90 Industrial Circular Power Connectors range in more detail, including body styles, contact options, sealing performance, electrical ratings, accessories, and target applications.

Fill in the form below to download the Product Training Module.
Your download will be available immediately after submission.

Download Now

Need more information?
Contact Us | Request Sample

Summary

Harwin Industrial Circular Power Connectors are designed for reliable power connectivity in harsh industrial environments. With rugged construction, environmental sealing that exceeds IP67, up to 13A current rating, 500V AC / 700V DC capability, flexible contact counts, and multiple body styles, the C90 range offers a dependable solution for industrial machinery, robotics, outdoor signaling, wireless base stations, construction vehicles, and other demanding applications

View Product

Maintain Reliable PCB Contact in Space-Constrained Designs

Compact SMT contact solutions engineered for dependable electrical connections.

In compact electronic assemblies, maintaining reliable electrical contact is essential for stable system performance. Harwin Spring Contact Fingers are designed to provide dependable electrical contact through controlled mechanical compression between a PCB and its mating surface.

During assembly, the contact compresses against the mating surface, generating continuous contact pressure to help maintain reliable electrical continuity. This makes Spring Contact Fingers well suited for designs where space is limited, mechanical tolerances must be accommodated, or repeated contact is required.



Key Features:

Harwin Spring Contact Fingers are available in SMT format for automated PCB assembly and are commonly used for grounding, RFI shielding, antenna contact, and general electrical contact applications. Depending on the selected part number, the range supports working heights from approximately 0.90mm to 6.95mm, current ratings up to 14A, and durability of up to 10,000 mating cycles. Finish options include gold and tin, with tape-and-reel packaging available for efficient automated assembly.

Key Highlights

✔ Compact SMT contact design

✔ Maintains reliable contact pressure during mating

✔ Suitable for wiping and sliding contact applications

✔ Compact footprint for space-constrained PCB layouts

✔ Available in gold or tin finish options

✔ Tape-and-reel packaging for automated assembly

✔ Supports grounding, shielding, antenna contact, and PCB-to-enclosure connections

Application and Market

Harwin Spring Contact Fingers are suitable for electronic applications that require reliable electrical contact within a compact PCB assembly.

Typical applications include:

• PCB grounding
• EMI/RFI shielding
• Antenna contact
• Board-to-board contact
• LED lighting assemblies
• RFID devices
• Vision systems

These contact solutions are commonly integrated into compact electronic products across industries such as automotive, industrial electronics, medical devices, wireless communications, and defense, depending on the application and system requirements.

Engineering Background:

In connected streetlight systems, engineers must integrate communication electronics into limited enclosure space. The unit must remain lightweight, self-contained, and easy to install on existing lighting infrastructure.

Traditional connection methods can increase space requirements, weight, or assembly complexity. For compact smart city electronics, the PCB connection method must support efficient production while maintaining a reliable interface between internal boards.

Harwin Solution

Harwin offers a comprehensive range of SMT Spring Contact Fingers in various heights, styles, contact forces, and finish options to support different PCB design requirements. The range is designed for automated assembly while providing dependable electrical contact in compact electronic systems.

Whether used for grounding, shielding, antenna contact, or PCB-to-enclosure connections, Harwin Spring Contact Fingers provide engineers with a compact and reliable SMT contact solution for modern electronic designs.



Download the Harwin Spring Contact Finger Technical Specifications

Access detailed product information, including dimensions, working heights, current ratings, finish options, packaging details, and selection guidance to help you choose the right Spring Contact Finger for your PCB design.

👉 Fill in the form below to download the Harwin Spring Contact Finger Technical Specifications.

Download Now

Need more information?
Contact Us | Request Sample

Summary

Harwin Spring Contact Fingers provide a compact SMT contact solution designed to maintain reliable electrical contact in modern electronic assemblies. Through controlled mechanical compression, they help support grounding, shielding, antenna contact, and PCB-to-enclosure connections where reliability, space efficiency, and consistent electrical performance are essential.

View Product

LS Materials Ultracapacitor Cells for High-Power Energy Support

Designed for fast charge/discharge, high power performance, and dependable energy support in demanding industrial and energy-related applications

LS Materials Ultracapacitor Cells are high-power energy storage components designed to support applications that require rapid energy delivery, frequent charge/discharge operation, and long-term reliability.

Unlike batteries, ultracapacitors store energy through a static charge mechanism, making them suitable for applications with high current demand over short durations. With their wide operating temperature range and maintenance-free characteristics, LS Materials Ultracapacitor Cells help support reliable performance across power backup, stabilization, industrial automation, and energy-related designs.



Key Features

✔ High Power Performance
Supports high power output for short-duration energy demand.

✔ Fast Charge/Discharge Capability
Designed for applications requiring rapid energy delivery and recovery.

✔ Low Internal Resistance
Helps support efficient power performance in demanding designs.

✔ Long Cycle Capability
Suitable for applications with repeated charge and discharge requirements.

✔ Maintenance-Free Design
Supports long-term use with reduced maintenance needs.

✔ Wide Operating Temperature Range
Designed to operate across demanding environments from -40°C to 65°C.

Why Ultracapacitor Cells Matter in Power Design

A simple look at how ultracapacitor cells support fast energy delivery, high power demand, and repeated cycling.

1. Respond Fast
   Supports rapid energy delivery for short-duration power demand.
2. Deliver High Power
   Suitable for applications that require high power within a short time.
3. Cycle Repeatedly
   Supports frequent charge and discharge operation.
4. Reduce Maintenance
   Maintenance-free design helps support long-term reliability.
5. Application & Market
   LS Materials Ultracapacitor Cells support applications that require high power, fast response, and
   reliable energy storage performance.

Applications & Target Markets

LS Materials Ultracapacitor Cells are suitable for energy storage applications that require frequent charge and discharge cycles, high current support, and short-duration power delivery.

According to the LSUC 002R8S 0120F EA datasheet, the ultracapacitor cell can be applied in:

• Wind power
• Hybrid systems
• Industrial automation
• Power backup
• Stabilization applications

These applications are commonly related to power electronics, renewable energy systems, industrial equipment, and backup power designs where fast energy response, repeated cycling, and dependable energy support are required.



Download the LSUC 002R8S 0120F EA Ultracapacitor Cell Datasheet

Access detailed specifications, electrical performance data, thermal information, mechanical dimensions, compliance details, and life information to better understand this LS Materials Ultracapacitor Cell for your power design requirements.

Complete the form below to access LS Materials Ultracapacitor Cell Datasheet and explore suitable options for your next project.

Download Datasheet Now

Need more information?
Request a Sample | Contact Sales



Summary

LS Materials Ultracapacitor Cells are designed to support fast energy delivery, high power performance, and repeated charge/discharge operation in demanding applications. With maintenance-free characteristics, wide operating temperature support, and long cycle capability, they provide a reliable component-level energy storage option for industrial, power backup, renewable energy, and mobility-related designs.

View Product

Powering Mission-Critical UAVs with Reliable 60A Connectivity

High-current cable-to-board power connectors engineered for defense, security and demanding UAV battery systems.

Modern UAV platforms are required to carry more than just cameras. In defense and security applications, they may support surveillance, threat detection, ground asset tracking, disaster management, search and rescue, and crowd control.

As payload systems become more advanced, battery power connection becomes a critical part of the UAV design. Cameras, sensors and high-current payload electronics depend on stable power delivery throughout the mission — from take-off to landing.

In this application, the UAV required a reliable battery-to-board power connection capable of supporting continuous 60A current to a high-current payload. Harwin Kona was selected to provide the high-reliability connection needed for this demanding UAV power system.

Key Features

• High-current cable-to-board power connection
• Supports 60A current-carrying capacity
• 2-contact female cable connector mated to male PCB connector
• Suitable for demanding UAV battery power systems
• Supports secure cable termination with solder cups
• Help enable easier battery to disconnect and replacement
• Designed for high-reliability applications where power continuity is critical



Application and Market

Harwin Kona is suitable for UAV platforms and mission-critical electronic systems where compact, reliableand high-current power connectivity is required:

Typical applications include:

• Defense and security UAVs
• Surveillance Drones
• Search and rescue UAV platforms
• Disaster response systems
• Ground asset tracking applications
• High-current sensor payloads
• Battery-powered aerospace electronics
• Rugged cable-to-board power systems

For UAVs operating in demanding environments, connector reliability directly supports mission uptime, payload stability and field serviceability.



Engineering Background

In a UAV power system, the battery-to-board connection must deliver current consistently while withstanding the demands of airborne operation. Movement, vibration, environmental changes and repeated battery handling can all place stress on the connector system.

The case study application involved a UAV platform operating up to 4,500 meters with temperature and humidity certification. The system required continuous 60A current from the battery to a high-current payload through a cable-to-board connection. The cable connector also required solder cups to support secure cable termination.

For engineers, this means the connector must do more than simply complete the circuit. It must provide a stable power path, reduce the risk of intermittent power loss and support reliable operation in a compact UAV design.

Harwin Solution

Harwin Kona provides the required high-current connection for this UAV battery power application.

The solution uses a Kona 2-contact female cable connector mated to a male PCB connector, delivering the high-reliability connection and 60A current-carrying capacity required by the payload system.

The PCB connector is positioned on the battery side, allowing the battery to be disconnected and replaced more easily when required. This supports practical serviceability, faster battery access and dependable power delivery during mission-critical operations.

Harwin Kona is designed for applications where high current, compact size and reliability are essential — making it a strong choice for demanding UAV, defense and security electronics.



Download Product Training Module — Harwin Kona

Access the Harwin Kona Product Training Module to learn more about its features, high-current performance, connector configuration and suitable applications.

Fill in the form below to download the Harwin Kona Product Training Module. Your download will be available immediately after submission.

Complete the short form to access full guide

Download Now

Need more information?
Contact Us | Request Sample



Summary

Defense and security UAVs depend on stable battery power to support cameras, sensors and high-current payload systems throughout the mission.

Harwin Kona provides a compact, high-reliability cable-to-board power connection with 60A current-carrying capacity, helping engineers design dependable UAV battery systems for demanding operating environments.

Reliable UAV power starts at the connection point.

View Product
